      Power supply - QUINT4PS1AC12DC75

      Reference number: QUINT4PS1AC12DC75.

      Product parameters:

      • 1st secondary output voltage: 12-15, 12-15V
      • Built-in height: 106
      • Built-in width: 45
      • Depth: 90, 90mm
      • Direct mounting possible: No, Nie
      • Height: 106, 106mm
      • Insulation class: 20
      • Manufacturer Product ID: 2904607
      • Max. output current 1: 12.8
      • Modular version: No, Nie
      • Nominal value output current 1: 7.5
      • Nominal value output voltage 1: 12
      • Output power: 90
      • Output voltage stabilised: Yes, Tak
      • Performance level acc. EN ISO 13849-1: n/a
      • Power consumption: 96.3
      • Rail mounting possible: Yes, Tak
      • Rated supply voltage at AC 50 Hz: 100-240, 100-240V
      • Rated supply voltage at AC 60 Hz: 100-240, 100-240V
      • Rated supply voltage at DC: 88-350
      • Secondary voltage adjustable: Yes, Tak
      • Short-circuit-proof: Yes, Tak
      • SIL according to IEC 61508: None
      • Stabilised: Yes, Tak
      • Suitable for safety functions: Yes, Tak
      • Voltage type of supply voltage: AC | DC, AC|DC
      • Wall mounting possible: No, Nie
      • Width: 45, 45mm
      Phoenix Contact
      QUINT4PS1AC12DC75

      Data sheet

      Width
      45
      45mm
      Height
      106
      106mm
      Depth
      90
      90mm
      Power consumption
      96.3
      Insulation class
      20
      20
      Manufacturer Product ID
      2904607
      Nominal value output voltage 1
      12
      12
      Output power
      90
      Suitable for safety functions
      Tak
      Yes
      Modular version
      Nie
      No
      Voltage type of supply voltage
      AC | DC
      AC|DC
      Rated supply voltage at DC
      88-350
      SIL according to IEC 61508
      None
      None
      Rail mounting possible
      Tak
      Yes
      1st secondary output voltage
      12-15
      12-15V
      Max. output current 1
      12.8
      Secondary voltage adjustable
      Tak
      Yes
      Short-circuit-proof
      Tak
      Yes
      Rated supply voltage at AC 50 Hz
      100-240
      100-240V
      Rated supply voltage at AC 60 Hz
      100-240
      100-240V
      Wall mounting possible
      Nie
      No
      Built-in width
      45
      Built-in height
      106
      Nominal value output current 1
      7.5
      Output voltage stabilised
      Tak
      Yes
      Stabilised
      Tak
      Yes
      Direct mounting possible
      Nie
      No
      Performance level acc. EN ISO 13849-1
      n/a
