Data sheet

Width

45
45mm

Height

85
85mm

Depth

97
97mm

Manufacturer Product ID

277298

Operating voltage AC 50 Hz

110-110
110-110V

Operating voltage AC 60 Hz

24-690
24.0-690.0V

Voltage type

AC
AC

Rated control supply voltage Us at AC 50HZ

110-110

Rated control supply voltage Us at AC 60HZ

110-110

Number of normally open contacts as main contact

3
3

Rated operating current (Ie) at AC-1, 400 V

45
45A

Rated operating current (Ie) at AC-3, 400 V

32

Rated operation power at AC-3, 400 V

15

Rated operation current Ie at AC-4, 400 V

15

Rated operation power at AC-4, 400 V

7

Number of auxiliary contacts as normally open contact

Modular version

Nie
No

Number of auxiliary contacts as normally closed contact

1
1

Rated control supply voltage Us at DC

0-0
0.0-0.0V

Type of electrical connection of main circuit

Połączenie śrubowe
Screw connection

Rated operation power NEMA

14.9

Number of normally closed contacts as main contact
