Data sheet

Width

129
129mm

Height

273
273mm

Depth

175
175mm

Power consumtion

209

Insulation class

20
20

Manufacturer Product ID

185758

Number of analogue inputs

2
2

Number of digital inputs

4
4

Number of digital outputs

1
1

Number of HW-interfaces industrial Ethernet

Supporting protocol for ASI

Nie
No

Supporting protocol for AS-Interface Safety at Work

Nie
No

Supporting protocol for CAN

Tak
Yes

Supporting protocol for Data-Highway

Nie
No

Supporting protocol for DeviceNet

Nie
No

Supporting protocol for DeviceNet Safety

Nie
No

Supporting protocol for EtherNet/IP

Tak
Yes

Supporting protocol for Foundation Fieldbus

Nie
No

Supporting protocol for INTERBUS

Nie
No

Supporting protocol for INTERBUS-Safety

Nie
No

Supporting protocol for KNX

Nie
No

Supporting protocol for LON

Nie
No

Supporting protocol for Modbus

Tak
Yes

Supporting protocol for other bus systems

Tak
Yes

Supporting protocol for PROFIBUS

Nie
No

Supporting protocol for PROFINET CBA

Nie
No

Supporting protocol for PROFINET IO

Nie
No

Supporting protocol for PROFIsafe

Nie
No

Supporting protocol for SafetyBUS p

Nie
No

Supporting protocol for SERCOS

Nie
No

Supporting protocol for SUCONET

Nie
No

Supporting protocol for TCP/IP

Nie
No

With optical interface

Nie
No

Mains voltage

380-480
380.0-480.0V

Mains frequency

50 | 60
50|60Hz

Number of phases input

3
3

Number of phases output

3
3

Max. output frequency

500
500Hz

Max. output voltage

500
500V

Nominal output current I2N

14

Max. output at quadratic load at rated output voltage

5,5kA
5.5

Max. output at linear load at rated output voltage

5,5kA
5.5

Relative symmetric net frequency tolerance

10
10%

Relative symmetric net voltage tolerance

10
10%

Number of analogue outputs

1
1

With control element

Tak
Yes

Application in industrial area permitted

Tak
Yes

Application in domestic- and commercial area permitted

Tak
Yes

Supporting protocol for BACnet

Nie
No

Number of HW-interfaces RS-485

1
1

Number of HW-interfaces other

With PC connection

Tak
Yes

Integrated breaking resistance

Tak
Yes

4-quadrant operation possible

Tak
Yes

Type of converter

Przemiennik napięciowy
U converter

Number of HW-interfaces RS-232

Number of HW-interfaces serial TTY

Number of HW-interfaces parallel

Number of HW-interfaces RS-422

Number of HW-interfaces USB

Number of interfaces PROFINET

Specific References
