Data sheet

Width

80
80mm

Height

102
102mm

Depth

137
137mm

Manufacturer Product ID

207081

Type of control element

Krótka rączka obrotowa
Short thumb-grip

Colour control element

Black
Czarny

Rated operation power at AC-3, 400 V

5,5kW
5.5

Number of auxiliary contacts as normally open contact

Number of auxiliary contacts as normally closed contact

Number of poles

3
3

Degree of protection (IP), front side

65
65

Device construction

Complete device in housing
Complete device in housing

Interlockable

Nie
No

Max. rated operation voltage Ue AC

690
690V

Motor drive integrated

Nie
No

Motor drive optional

Nie
No

Number of switches

1
1

Rated operating voltage

690-690
690.0-690.0V

Rated operation power at AC-23, 400 V

5,5kW
5.5

Rated permanent current at AC-21, 400 V

20
20A

Rated permanent current at AC-23, 400 V

13,3A
13.3

Rated permanent current Iu

20
20A

Suitable for distribution board installation

Nie
No

Suitable for front mounting 4-hole

Nie
No

Suitable for front mounting centre

Nie
No

Suitable for intermediate mounting

Nie
No

Switching power at 400 V

5,5kA
5.5

Type of electrical connection of main circuit

Połączenie śrubowe
Screw connection

Version as emergency stop installation

Nie
No

Version as main switch

Nie
No

Version as maintenance-/service switch

Nie
No

Version as reversing switch

Nie
No

Version as safety switch

Nie
No

Voltage release optional

Nie
No

Conditioned rated short-circuit current Iq

6
6kA

Number of auxiliary contacts as change-over contact

Rated short-time withstand current lcw

0,3kA
0.3

With pre-assembled cabling

Nie
No
