      Relay - 403190120000
      Relay - 403190120000
      Relay - 403190120000
      Relay - 403190120000

      Relay - 403190120000

      Review (0)
      zł27.87
      Tax Included
      Return policy:14
      Relay - 403190120000 - Complete with socket: No, Nie; Contact type: Single contact, Pojedynczy.
      Quantity :
      • Polityka bezpieczeństwaPolityka bezpieczeństwa
      • Zasady dostawyZasady dostawy
      • Zasady zwrotuZasady zwrotu

      Relay - 403190120000

      Reference number: 403190120000.

      Product parameters:

      • Complete with socket: No, Nie
      • Contact type: Single contact, Pojedynczy
      • Depth: 29, 29mm
      • Drive, polarization: Polarity free, Niespolaryzowany
      • Drive, switching attitude: Mono stable, Monostabilny
      • Height: 25, 25mm
      • Manufacturer Product ID: 40.31.9.012.0000
      • Material of contact surface: Silver cadmium oxide (AgCdO)
      • Max. starting current: 20, 20A
      • Nominal current: 16, 16A
      • Number of contacts as change-over contact: 1
      • Number of contacts as normally closed contact: 1
      • Number of contacts as normally open contact: 1
      • Operating voltage DC: 8.8-18.0, 8.8-18.0V
      • Rated control supply voltage Us at DC: 12.0-12.0, 12.0-12.0V
      • Relay technology category according to IEC 61810-7: RT II
      • Type of electric connection: PCB connection, Złącze PCB
      • Voltage type (operating voltage): DC
      • Voltage type for actuating: DC
      • Width: 12.4, 12,4mm
      • With detachable clamps: No, Nie
      • With forced-guided contacts: No, Nie
      • With LED indication: No, Nie
      Finder
      403190120000

      Data sheet

      Width
      12,4mm
      12.4
      Height
      25
      25mm
      Depth
      29
      29mm
      Type of electric connection
      PCB connection
      Złącze PCB
      With detachable clamps
      Nie
      No
      Manufacturer Product ID
      40.31.9.012.0000
      Operating voltage DC
      8.8-18.0
      8.8-18.0V
      Number of contacts as normally closed contact
      1
      1
      Number of contacts as normally open contact
      1
      1
      Number of contacts as change-over contact
      1
      1
      With LED indication
      Nie
      No
      Material contact
      Silver nickel (AgNi)
      Material of contact surface
      Silver cadmium oxide (AgCdO)
      Type of switch contact
      Pojedynczy
      Single contact
      Max. starting current
      20
      20A
      Complete with socket
      Nie
      No
      Rated control supply voltage Us at DC
      12-12
      12.0-12.0
      12.0-12.0V
      Voltage type for actuating
      DC
      DC
      Drive, polarization
      Niespolaryzowany
      Polarity free
      Drive, switching attitude
      Monostabilny
      Mono stable
      With forced-guided contacts
      Nie
      No
      Voltage type (operating voltage)
      DC
      DC
      Nominal current
      16
      16A
      Relay technology category according to IEC 61810-7
      RT II
      RT II
