Data sheet

Width

22,5mm
22.5

Height

79
79mm

Depth

100
100mm

Insulation class

20
20

Type of electric connection

Połączenie śrubowe
Screw connection

Manufacturer Product ID

H3DK6015H

Material of contact surface

Gold

Complete with socket

Nie
No

Rated control supply voltage Us at DC

12-12
12.0-12.0V

Voltage type for actuating

DC
DC

Voltage type (operating voltage)

DC
DC

Nominal current

5
5A

Relay technology category according to IEC 61810-7

RT I
RT I

Clock function, starting with pause, variable

Nie
No

Clock function, starting with pulse, variable

Tak
Yes

Function delay on de-energization

Tak
Yes

Function delay-on energization

Tak
Yes

Function flashing, starting with pulse, fixed time

Tak
Yes

Function floating contact on de-energization

Tak
Yes

Function floating contact on energization

Tak
Yes

Function pulse shaping

Nie
No

Function star-delta

Nie
No

Number of outputs, delayed, change-over contact

2
2

Outputs, reversible delayed/undelayed

Nie
No

Pluggable on auxiliary contact block

Nie
No

Remote operation possible

Nie
No

Suitable for DIN rail (top hat rail) mounting

Yes

Suitable for remote control

Nie
No

Time range

0.1-4320000.0
0.1-4320000.0s

With semiconductor output

Nie
No

Number of outputs, delayed, normally open contact

Number of outputs, undelayed, change-over contact

Number of outputs, undelayed, normally open contact

Suitable for front mounting

No
