Data sheet

Insulation class

65

Housing material

Metal
Zamak
Zamak

Type of electric connection

Cable entry PG

Manufacturer Product ID

ZCKJ1

Switching function latching

No

Type of control element

None

Rated operation current Ie at AC-15, 230 V

3

Number of contacts as normally closed contact

1

Number of contacts as normally open contact

1

Number of contacts as change-over contact

Suitable for safety functions

No

With status indication

No

Length of sensor

44

Switching function

Quick-break switch

Ambient temperature during operating

-25.0

Protection type

IP66
IP66

Width sensor

40

Cable entry

PG13
PG13

Forced opening

Yes

Height of sensor

81.5

Output electronic

No

Rated operation current Ie at DC-13, 230 V

0.27

Type of interface

None

Type of interface for safety communication

None

Number of safety auxiliary contacts

Switching capacity (AC-15 230V) (A)

3
3A

Number of NC contacts

1
1

Number of NO contacts

1
1

Switching capacity (DC-13 220V)

0,27A
0.27

Lifespan, electrical (Operations)

5x10E6
5x10E6

Lifespan, mechanical (Operations)

30x10E6
30x10E6

According to norm

IEC 60947-5-1EN 60947-5-1UL 508CSA C22-2 n° 14
IEC 60947-5-1||EN 60947-5-1||UL 508||CSA C22-2 n° 14
